Tefen PP Black BSPT 1/2" Male Elbow Conn - Fits 16mm OD Hose
Description
Tefen barb connectors are push fit connectors (no need for hose clamp), designed to operate with all PE tubes class 2.5-4 PN, at the range. Can work with other flexible plastic and rubber pipes. The fittings and sealing mechanism are based on a barb that holds the tube from the inside diameter. Fittings size indicate the nominal outside diameter of the tube. For example; 5/8" barb fitting, fits a 5/8" irrigation tube class 2.5, with inner diameter of 1/2".
BSP- BSPT Fitting Guide
Downloads
Note on choosing the correct part
- Fits Hose/Tube ID - refers to the inner Diameter of the Hose/Tube you are using with the Tefen Fitting
- Fits Irrigation Hose/Tube OD - refers to the Outer Diameter of commonly used irrigation hoses
Product Specifications
- Fits Hose/Tube OD mm (Irrigation) 16.0
- Male (M) BSPT inch 1/2
- Length (L) mm 51.6
- Length (L1) mm 39.5
- Working Pressure14 Bar/200 PSI (@20°C)
- Min Temp °C4
- Max Temp °C90
- Material Polypropylene
- Manufactured By Tefen
Features
- Strong and durable
- High impact resistance
- UV resitant
- TSCA compliant
Original: $2.05
-65%$2.05
$0.72More Images
